ProCharger 2015-19 C7 Corvette Z06 LT4 Supercharger F-1A-94/F-1C/F-1R Pro Race Tuner Kit 1GU500-94
- PART NUMBER:
- 1GU500-94
- MPN:
- 1GU500-94
- Availability:
- Ships from Manufacturer
- Shipping:
- Free Over $98 In U.S. 48
- Type:
- C7 Corvette Supercharger Tuner Kit
- Compressor Included:
- Yes
- Compressor Style:
- See Options
- Drive System:
- add'l 8 Rib
- Blow Off Valve Included:
- Yes
- Blow Off Valve Style:
- Race
- Intercooler Included:
- Yes
- Fuel Injectors Included:
- No
- ECM Tuning Included:
- No
- Quantity:
- Sold as a kit
Description
ProCharger 2015-19 C7 Corvette Z06 LT4 Supercharger F-1A-94/F-1C/F-1R Pro Race Tuner Kit 1GU500-94
825+ HP FROM A FACTORY LT-4 WITH NO OTHER MODS
ProCharger was the first supercharger manufacturer to design and release an air-to-air intercooled supercharger system for the C7 Corvette Stingray, but we didn’t stop there. ProCharger now has a robust centrifugal supercharger kit offering for Chevrolet’s ultimate supercar–the 2019-2015 C7 Z06 Corvette. By replacing the Z06’s LT4 factory roots-style supercharger with a direct-replacement sheet metal intake manifold and centrifugal supercharger head unit, all while still fitting comfortably under the factory hood on both the LT1 and LT4 Corvette engines, a ProCharger dramatically increases the horsepower and torque output.
GM laid the foundation for big power with the C7 Z06 LT4 engine’s forged internals, relatively low compression, and factory-supercharger system, and now with the addition of a ProCharger supercharger you can bolt-on an extra 115+ HP over stock with an intercooled D-1SC head unit at the 10 psi factory boost level and pump gas, with no permanent modifications to the vehicle. At 13 psi, while still running pump gas and factory timing, 825 HP is at your fingertips. For those that are really looking to have a spot on the map of big horsepower, check out our Race kits page.
Tuner Kits: These kits make sense for someone wanting to perform custom tuning of the car and push the envelope in performance. Will most likely be experimenting with alternative fuels such as 93 octane, race fuel, E85 fuel, and methanol supplemental fuel. In addition, possibly changing engine components like heads, headers, exhaust, and cams for the engine. No tuning or fuel components provided.
2019-2015 CORVETTE C7 Z06 (LT4) FEATURES:
Our 2019-2015 Corvette C7 Z06 High Output Intercooled Tuner Kits with D-1SC were engineered for a 115+ horsepower gain over stock on 10 psi of boost and pump gas. Higher boost levels and horsepower gains of 825 HP are possible on 13 psi, and even higher for custom racing builds equipped with a ProCharger F-Series supercharger model up to the 10.5” volute (F-1X and F-2), all without the need for additional brackets.
BLOWER OPTIONS
From mild to wild, ProCharger has a supercharger head unit ready to support whatever power level you desire. The base system comes with the super-efficient D-1SC supercharger, capable of 800+ RWHP (925 HP), and race systems are available up to the F-2 unit which can support 1,600 HP. Each ProCharger supercharger model features our patented self-contained design with its own internal oiling system, and is built out of aircraft grade billet aluminum for the ultimate in reliability.
- 10 Rib Gates HD Drive Belts
- (2) Balancer size options for perfect blower RPM
AIR-TO-AIR INTERCOOLER
It’s a simple fact of physics: cooler air makes more power. On street driven vehicles, air-to-air intercooling is a natural fit because it locates the intercooler at the front of the vehicle where it is exposed to a constant supply of cooling airflow. Experts agree that air-to-air inherently provides better cooling and reliability than air-to-water intercoolers for street use. Engineered with large-volume air plenums, ProCharger’s air-to-air intercoolers utilize a highly effective and extremely durable bar and plate intercooler core design that provides large surface areas for superior levels of heat dispersion.
REVERSIBILITY
The installation of our C7 and C7 Z06 HO Intercooled Systems is 100% reversible, with no permanent modifications needed to the vehicle. The factory supercharger and supporting components/hardware are easily unbolted and removed and can be reinstalled just as easily. From our bolt-in intake manifold, blower bracket, to the air-to-air intercooler system, everything is 100% plug-and-play. No cutting, bending, tweaking, or trimming of any kind is needed.
SYSTEM OPTIONS
These ProCharger systems also give Corvette owners multiple options in both the performance and appearance arenas, with your choice of a supercharger air inlet with race-style filter or a factory air box interface, and either polished, satin, or black finish for the brackets and head unit.
Head Units:
– D-1SC through F-2
Head Unit and Bracket Finishes:
– Satin
– Texture Black
– Polished
Intake Manifold and Top Plate/Cover Finishes:
– Unfinished
– Texture Black
Bypass Valves:
– Bullet ProFlow
– Race Valve (open or closed)
Footnotes:
1.) Model year and manual or automatic transmission must be specified
2.) Satin finish is now standard for Corvette systems; polished finish and black finish is optional
5.) System ships in extra large box
6.) Specify stock or aftermarket balance(ATI Balancer Part Numbers: LT1 Dry #917315, LT1 Wet #917314, Z06 LT4 #917315; specify hardened hub)
9.) F-1X supercharger upgrade requires modifications
10.) Two-part shipment, additional shipping charges may apply
11.) Works with maximum of 10% overdrive crank pulley
12.) Ice-tank mount welding, wiring, sway bar removal, vehicle trimming and modifications required
13.) Port injection Option requires LS3/38mm length injectors
